Frequency

Mounting

Application

2JW0124z-C868B

2JW0124z-C868B

Download Data Sheet

Dimensions

Dimensions (mm) 171 × 38 × 13.8
Operating temperature -40 °C to +85 °C

Specification

Standards GSM, CDMA, DCS, PCS, GPRS, WCDMA, UMTS, HSPA, EVDO and LTE
Frequency 698-960, 1710-2170, 2500-2700
VSWR ~2.4:1, ~1.6:1, ~2.2:1
Efficiency (%) ~62, ~75, ~50
Peak Gain (dBi) ~0.4, ~2.6, ~1.3
Impendance (Ohm) 50
Polarisation Linear
Max. Input Power (W) 25
